Redux Toolkit: an example

🧠 Redux Toolkit – A Real-World Example: User Authentication

Redux Toolkit (RTK) is the official, recommended approach for writing Redux logic. But it can be easy to forget and miss on the structure when you haven't work in it for a while or you join a new project that build its structure long time ago.

For that reason I wanted to create this article that works as a refresher summary where I define every file and the purpose by means of examples.

🧩 Core Concepts

| Concept             | Purpose                                                              |
|---------------------|-----------------------------------------------------------------------|
| `configureStore`    | Creates the Redux store with sensible defaults                        |
| `createSlice`       | Combines reducer, action creators, and initial state in one           |
| `createAsyncThunk`  | Manages async logic and auto-generates pending/fulfilled/rejected     |
| `useDispatch`       | React hook to dispatch actions                                        |
| `useSelector`       | React hook to access store state                                      |

🧪 Real-World Use Case: User Authentication

We'll create a small app where:

• A user can log in
• JWT token and user data are stored in Redux state
• Token is persisted in localStorage
• Auth state is accessed across components

📁 Suggested Folder Structure

src/
├── app/
│ └── store.js # Store configuration
├── features/
│ └── auth/
│ ├── authSlice.js # Redux slice for auth
│ └── authAPI.js # API logic
├── components/
│ └── LoginForm.jsx

🛠 Step-by-Step Guide

1. store.js – Create the store

    //src/app/store.js
    import { configureStore } from '@reduxjs/toolkit'
    import authReducer from '../features/auth/authSlice'

    export const store = configureStore({
      reducer: {
        auth: authReducer,
      },
    })

2. authSlice.js – Auth logic with createAsyncThunk

    // src/features/auth/authSlice.js
    import { createSlice, createAsyncThunk } from '@reduxjs/toolkit'
    import { loginAPI } from './authAPI'

    const token = localStorage.getItem('token')

    const initialState = {
      user: null,
      token: token || null,
      status: 'idle',
      error: null,
    }

    export const loginUser = createAsyncThunk(
      'auth/loginUser',
      async (credentials, thunkAPI) => {
        try {
          const response = await loginAPI(credentials)
          return response
        } catch (err) {
          return thunkAPI.rejectWithValue(err.message)
        }
      }
    )

    const authSlice = createSlice({
      name: 'auth',
      initialState,
      reducers: {
        logout: (state) => {
          state.user = null
          state.token = null
          localStorage.removeItem('token')
        },
      },
      extraReducers: (builder) => {
        builder
          .addCase(loginUser.pending, (state) => {
            state.status = 'loading'
          })
          .addCase(loginUser.fulfilled, (state, action) => {
            state.status = 'succeeded'
            state.user = action.payload.user
            state.token = action.payload.token
            localStorage.setItem('token', action.payload.token)
          })
          .addCase(loginUser.rejected, (state, action) => {
            state.status = 'failed'
            state.error = action.payload
          })
      },
    })

    export const { logout } = authSlice.actions
    export default authSlice.reducer

3. authAPI.js – Fake API login

    // src/features/auth/authAPI.js
    export const loginAPI = async ({ email, password }) => {
      if (email === 'admin@site.com' && password === '123456') {
        return {
          user: { id: 1, name: 'Admin', email },
          token: 'fake-jwt-token-123',
        }
      } else {
        throw new Error('Invalid credentials')
      }
    }

4. LoginForm.jsx – Component using the auth state

    // src/components/LoginForm.jsx
    import React, { useState } from 'react'
    import { useDispatch, useSelector } from 'react-redux'
    import { loginUser } from '../features/auth/authSlice'

    export default function LoginForm() {
      const dispatch = useDispatch()
      const auth = useSelector((state) => state.auth)
      const [email, setEmail] = useState('')
      const [password, setPassword] = useState('')

      const handleLogin = (e) => {
        e.preventDefault()
        dispatch(loginUser({ email, password }))
      }

      return (
        <form onSubmit={handleLogin}>
          <input
            type="email"
            value={email}
            onChange={(e) => setEmail(e.target.value)}
            placeholder="Email"
          />
          <input
            type="password"
            value={password}
            onChange={(e) => setPassword(e.target.value)}
            placeholder="Password"
          />
          <button type="submit">Login</button>

          {auth.status === 'loading' && <p>Loading...</p>}
          {auth.error && <p style={{ color: 'red' }}>{auth.error}</p>}
          {auth.user && <p>Welcome, {auth.user.name}!</p>}
        </form>
      )
    }

💡 What You Get

✅ Centralized user auth state
✅ Automatic loading/error handling
✅ Token stored in localStorage
✅ Easy access to user across the app
✅ Scalable, testable, and clean setup

🔐 Bonus: Rehydrate Token on App Load

    // in App.jsx or a layout component
    useEffect(() => {
      const token = localStorage.getItem('token')
      if (token && !auth.token) {
        // Optionally re-fetch user data here using a new thunk
        dispatch(rehydrateUserFromToken(token))
      }
    }, [])

You’d have to implement rehydrateUserFromToken as another createAsyncThunk if needed.

Redux Toolkit: Simple Analogies Summary

1. Store

Think of it as the central library where all your app’s state books live. It keeps everything organized and ready to be accessed or updated.

2. Slice (createSlice)

Imagine a book section in the library dedicated to one topic (like "auth" or "products"). It contains the state, the rules to update it (reducers), and the bookmarks (actions) to mark those updates.

3. Action

An instruction slip you send to the library saying “Please update this section like so.” It’s a simple message describing what you want changed.

4. Reducer

The librarian who reads the instruction slip (action) and updates the books (state) accordingly, making sure everything stays organized and consistent.

5. Thunk (createAsyncThunk)

The messenger who can go outside the library (perform async tasks like API calls), fetch new information, and then come back with instructions for the librarian to update the books.

6. configureStore

The library builder who sets up the library with the right sections (reducers), adds helpers (middleware like thunk), and ensures the system works smoothly.

7. useDispatch

Your mailbox to send instruction slips (actions) to the librarian.

8. useSelector

Your window to look inside the library and read the current state of any section you want.

This way, Redux Toolkit is like a well-run library with clear roles:

• You send requests (actions) through your mailbox (useDispatch).
• The librarian (reducer) updates the right section (slice) of the library.
• The messenger (thunk) can do errands (async work) before updating things.
• And you always have a window (useSelector) to see the latest info.

Now it's your turn. The best way to learn is to practice. Go build something on your own!
